| Operating temperature range |
Room temperature +10°C ~220°C |
Room temperature +15°C ~220°C |
| Operating vacuum range |
40-3.0 ~ -29.9 inHg (-10 ~ 101 kPa) |
| Vacuum display range |
0.0 ~ -29.9 inHg (5 to -101 kPa) |
760 Torr down to 0 mTorr |
| Controls |
EZ-ZONE Watlow |
| Access port |
KF25 |
| Temperature uniformity - midrange |
± 6.0% of setpoint |
Temperature stability
@ 80°C
@ 150°C
@ 220°C
|
± 0.1°C
± 0.20°C
± 0.3°C |
± 0.2°C
± 0.25°C
± 0.3°C |
± 0.2°C
± 0.2°C
± 0.3°C |
Heat up times @ 80°C
(from RT of 20°C for SDP300/400)@ 150°C
(from RT of 25°C for SDP610)@ 220°C
|
70 mins.
120 mins.
200 mins. |
70 mins.
120 mins.
230 mins. |
80 mins.
130 mins.
180 mins. |
Cool down times From @ 80°C
(time to cool down to 50°C)From @ 150°C
From @ 220°C
|
110 mins.
188 mins.
233 mins. |
161 mins.
318 mins.
420 mins. |
---
---
--- |
| Controller |
Digital |
| Display resolution |
0.1°C |
| Interior material |
300 SST |
| Exterior material |
Painted cold roll steel |
| Standard chamber gasket |
Silicone |
Viton |
| Internal dimensions |
W304 x D508 x H304 mm
12 × 20 × 12 in. |
W457 x D610 x H457 mm
18 × 24 × 18 in |
W710 x D609 x H609 mm
28 × 24 × 24 in |
| External dimensions WxDxH |
W528 x D795 x H681 mm
20.8 × 31.3 × 26.8 in |
W686 x D895 x H833 mm
27.0 × 35.2 × 32.8 in |
W965 x D1189 x H1624 mm
38.1 × 46.8 × 63.9 in |
| Internal capacity |
47.2L |
127.4L |
264L |
| Shelf dimensions (WxD) |
287 x 483 mm (11.3” x 19”) |
| Shelf capacity by weight per shelf *1 |
15.8 kg |
34 kg |
| Maximum total load *2 |
47.6 kg. |
102 kg |
| Shelf rest step number |
3 steps |
6 steps |
3 steps |
| Power source 50/60 Hz |
AC110 - 120V 10A
AC220 - 240 5.5A |
AC110 - 120V 13A
AC220 - 240V 7A |
AC230V 20A (no plug) |
| Weight |
~83kg |
~144kg |
~223kg |
| Included accessories |
3 shelves (2 tall, 1 short bottom), 1 power cord, 4 leveling feet |
3 shelves, 12 shelf clips, 1 power cord, 4 leveling feet |
3 shelves, 12 shelf clips, 4 leveling feet, oil drain tray |
| List Price |
$ 10,180 |
$ 19,575 |
$ 28,735 |
