| Exhaust Pipe |
Exhaust damper |
Stainless steel, inner diameter ø150,
outer diameter ø152, fixed by flange |
Hard polyethylene, inner diameter ø160,
outer diameter ø165, fixed by flange |
| Matched Pipe |
Hard polyethylene, inner diameter ø160, outer diameter ø165 |
| Fluorescent Light |
1 pc. |
| Water Exhaust Pipe |
Hard polyethylene / Single tube fixed (outer diameter ø40, inner diameter ø31) |
| Material |
Exterior |
Cold-rolled steel plate, chemical proofing powder coating, with adjusting casters |
| Interior |
Stainless steel (SUS 304) |
Hard polyethylene |
| Working face |
Stainless steel (SUS 304) |
Hard polyethylene |
| Glass door |
Toughened glass 5mm. Close and open (up and down) with balance block |
| Safety Structure |
Brake block to prevent door from falling
down / Door opening extent sticker |
Brake block to prevent door from
falling down / Motor of exhaust fan |
| Air Volume (M³/Min) *¹ |
7 |
| Internal Static Pressure Pa (Mm H₂O) |
40 (4) |
| Power Source (50/60Hz) |
Single phase 115V 10A or 220V 5A / Length of power cord: about 2m |
| Worktop |
Stainless steel (SUS304) |
Hard polyethylene |
| Worktop Load Bearing |
Uniformly-distributed load 50kg |
| Standard Type |
External dimensions |
W900 x D750 x H1850 mm |
| Weight (kg) |
~130 |
120 |
| Benchtop Type |
External dimensions |
W900 x D750 x H1000 mm |
| Weight (kg) |
~90 |
80 |
| Temp. And Humidity Condition Of Location |
5~35°C, 20~80% (no frosting) |
| Tap |
Gooseneck tap, nominal value 1/2B flexible tube, external or internal thread fixing |
| Device Of Waste Liquid |
Unit body (tray): cold-rolled steel plate (chemical proofing powder coating), with casters, 20L polyurethane bottle, connecting tools of draining water (nut, hose, steel wire hoop) |
| Included Accessories |
Fixing bolts for upper and lower bodies fixing, fixing fittings of wall and ground, tools for adjusting foot, cover of water outlet, shock pads, front operation panel |
Flange, bolts for flange fixing, fixing bolts for upper and lower bodies fixing, fixing fittings of wall and ground, tools for adjusting foot |
